REST API

Toolvico API Documentation

Build OTP activations and SMM ordering directly into your product. The API returns JSON, uses wallet billing in USD, and is protected by account API keys.

Base URLhttps://toolvico.com/api/v1
Formatapplication/json
AuthX-API-Key

Authentication

Send your API key with every request using the X-API-Key header. Generate and manage keys from Dashboard -> API Access.

curl "https://toolvico.com/api/v1/otp?action=balance" \
  -H "X-API-Key: your_api_key_here"

Rate Limits

API keys are limited to 60 requests per minute per endpoint. A rate limited response returns HTTP 429 with a Retry-After header.

Get Countries

GET /api/v1/otp?action=countries

Return available OTP countries. Pass server/provider_source for one public server, or omit it to merge enabled route sources.

Parameters

ParameterTypeRequiredDescription
server string No Public server: romeo, juliet, peter, paul, andrew, mark, luke, john, or all. provider_source/source are also accepted aliases.

Request Example

curl -X GET "https://toolvico.com/api/v1/otp?action=countries" \
  -H "X-API-Key: your_api_key_here"

Response

{
  "success": true,
  "data": {
    "countries": [
      { "id": "61", "key": "pakistan", "name": "Pakistan", "routes": [{"provider_type":1,"country_id":"61"}], "providers": ["peter"], "provider_country_ids": {"peter": ["61"]} },
      { "id": "13", "key": "unitedstates", "name": "USA", "providers": ["romeo"], "provider_country_ids": {"romeo": ["13", "188"]} }
    ],
    "provider_sources": ["romeo", "juliet", "peter", "paul", "andrew", "mark", "luke", "john"]
  }
}

Get Services

GET /api/v1/otp?action=services

List OTP services with marked-up USD prices. Pass server/provider_source plus country_id for one public server, or pass country_key and routes for all enabled route sources.

Parameters

ParameterTypeRequiredDescription
country_id string Conditional Route country ID. Required for single-source calls.
server string No Public server: romeo, juliet, peter, paul, andrew, mark, luke, john, or all. provider_source/source are also accepted aliases.
provider_type integer No Route server type for peter. Default 1.
country_key string No Merged country key from countries endpoint.
routes string No Comma-separated peter routes like 1:61,2:61.

Request Example

curl -X GET "https://toolvico.com/api/v1/otp?action=services&country_key=pakistan&routes=1:61" \
  -H "X-API-Key: your_api_key_here"

Response

{
  "success": true,
  "data": {
    "services": [
      { "service_id": "306343", "name": "Discord", "provider_source": "peter", "country_id": "61", "provider_type": 1, "your_price_usd": 0.040000, "success_rate": 86 },
      { "service_id": "tg", "name": "Telegram", "provider_source": "paul", "country_id": "6", "provider_type": 0, "your_price_usd": 0.180000, "success_rate": 91 }
    ],
    "provider_sources": ["romeo", "juliet", "peter", "paul", "andrew", "mark", "luke", "john"]
  }
}

Buy Number

POST /api/v1/otp?action=buy_number

Purchase an OTP number. Wallet is charged only if the route returns a number. Use server/provider_source, country_id, provider_type, and pool_id exactly as returned by get services.

Parameters

ParameterTypeRequiredDescription
service_id string Yes Service ID from get services.
country_id string Yes Route country ID from get services.
server string No Public server from get services. Default peter. provider_source/source are also accepted aliases.
provider_type integer No Route server type for peter. Default 1.
pool_id string No Pool ID when server is andrew.

Request Example

curl -X POST "https://toolvico.com/api/v1/otp?action=buy_number" \
  -H "X-API-Key: your_api_key_here" \
  -H "Content-Type: application/json" \
  -d '{"service_id":"306343","country_id":"61","server":"peter","provider_type":1}'

Response

{
  "success": true,
  "data": {
    "order_id": "42",
    "phone_number": "+923001234567",
    "provider_source": "peter",
    "charged_usd": 0.04,
    "status": "waiting"
  }
}

Get Status

GET /api/v1/otp?action=get_status

Poll an OTP order until it returns waiting, received, or cancelled.

Parameters

ParameterTypeRequiredDescription
order_id integer Yes Database order ID returned by buy number.

Request Example

curl -X GET "https://toolvico.com/api/v1/otp?action=get_status&order_id=42" \
  -H "X-API-Key: your_api_key_here"

Response

{
  "success": true,
  "data": { "status": "received", "code": "123456" }
}

Cancel

POST /api/v1/otp?action=cancel

Cancel a waiting OTP order after the minimum waiting period and refund wallet balance.

Parameters

ParameterTypeRequiredDescription
order_id integer Yes Database order ID.

Request Example

curl -X POST "https://toolvico.com/api/v1/otp?action=cancel" \
  -H "X-API-Key: your_api_key_here" \
  -H "Content-Type: application/json" \
  -d '{"order_id":42}'

Response

{
  "success": true,
  "data": { "refunded": true, "amount": "0.040000" }
}

Balance

GET /api/v1/otp?action=balance

Return your API wallet balance in USD.

Parameters

ParameterTypeRequiredDescription
none - No No parameters required.

Request Example

curl -X GET "https://toolvico.com/api/v1/otp?action=balance" \
  -H "X-API-Key: your_api_key_here"

Response

{
  "success": true,
  "data": { "wallet_balance": "12.450000", "currency": "USD" }
}

List Services

GET /api/v1/smm?action=services

Return active SMM services with marked-up USD rates per 1000 units.

Parameters

ParameterTypeRequiredDescription
none - No No parameters required.

Request Example

curl -X GET "https://toolvico.com/api/v1/smm?action=services" \
  -H "X-API-Key: your_api_key_here"

Response

{
  "success": true,
  "data": {
    "services": [
      { "service_id": "1", "name": "Followers", "category": "Instagram", "rate_usd_per_1000": 1.08, "min": 50, "max": 10000 }
    ]
  }
}

Place Order

POST /api/v1/smm?action=place_order

Create an SMM order and deduct wallet balance after provider acceptance.

Parameters

ParameterTypeRequiredDescription
service_id string Yes SMM service ID.
link string Yes Target URL/profile/video.
quantity integer Yes Quantity within service min and max.

Request Example

curl -X POST "https://toolvico.com/api/v1/smm?action=place_order" \
  -H "X-API-Key: your_api_key_here" \
  -H "Content-Type: application/json" \
  -d '{"service_id":"1","link":"https://instagram.com/user","quantity":500}'

Response

{
  "success": true,
  "data": { "order_id": "15", "charged": 0.540000, "status": "Pending" }
}

Order Status

GET /api/v1/smm?action=order_status

Poll SMM order status and sync start count, remains, and partial refunds.

Parameters

ParameterTypeRequiredDescription
order_id integer Yes Database order ID returned by place order.

Request Example

curl -X GET "https://toolvico.com/api/v1/smm?action=order_status&order_id=15" \
  -H "X-API-Key: your_api_key_here"

Response

{
  "success": true,
  "data": { "status": "Partial", "remains": 157, "start_count": 3572 }
}

Balance

GET /api/v1/smm?action=balance

Return your API wallet balance in USD.

Parameters

ParameterTypeRequiredDescription
none - No No parameters required.

Request Example

curl -X GET "https://toolvico.com/api/v1/smm?action=balance" \
  -H "X-API-Key: your_api_key_here"

Response

{
  "success": true,
  "data": { "wallet_balance": "12.450000", "currency": "USD" }
}

Error Codes

CodeMeaningHow to handle
401Invalid or missing API keyCheck the X-API-Key header.
402Insufficient wallet balanceTop up via dashboard.
403API access not enabledEnable API access in dashboard settings.
404Order or service not foundCheck the ID parameter.
429Rate limit exceededRetry after 60 seconds.
503Provider unavailableRetry later. Failed provider purchases are refunded.

Code Examples

These examples buy a number and poll until an OTP is received or cancelled.

PHP

final class OTPFlowClient {
    public function __construct(private string $baseUrl, private string $apiKey) {}

    public function request(string $path, array $body = null): array {
        $opts = ['http' => ['header' => "X-API-Key: {$this->apiKey}\r\nContent-Type: application/json\r\n"]];
        if ($body !== null) {
            $opts['http']['method'] = 'POST';
            $opts['http']['content'] = json_encode($body);
        }
        $json = file_get_contents($this->baseUrl . $path, false, stream_context_create($opts));
        return json_decode($json, true);
    }
}

$client = new OTPFlowClient('https://toolvico.com/api/v1', 'your_api_key_here');
$order = $client->request('/otp?action=buy_number', ['service_id' => '306343', 'country_id' => '61']);
$orderId = $order['data']['order_id'];

for ($i = 0; $i < 20; $i++) {
    sleep(6);
    $status = $client->request('/otp?action=get_status&order_id=' . $orderId);
    if (($status['data']['status'] ?? '') === 'received') {
        echo $status['data']['code'];
        break;
    }
}

JavaScript

const apiKey = 'your_api_key_here';

async function api(path, body) {
  const res = await fetch('/api/v1' + path, {
    method: body ? 'POST' : 'GET',
    headers: { 'X-API-Key': apiKey, 'Content-Type': 'application/json' },
    body: body ? JSON.stringify(body) : undefined
  });
  const json = await res.json();
  if (!json.success) throw new Error(json.error);
  return json.data;
}

const order = await api('/otp?action=buy_number', {
  service_id: '306343', country_id: '61'
});

const timer = setInterval(async () => {
  const status = await api('/otp?action=get_status&order_id=' + order.order_id);
  if (status.status === 'received') {
    clearInterval(timer);
    console.log('OTP:', status.code);
  }
}, 6000);
